Description
TP-Link EAP650-Outdoor AX3000 WiFi 6 Outdoor Access Point
High-Performance Outdoor WiFi 6 for Business & Commercial Networks
The TP-Link EAP650-Outdoor is an AX3000 outdoor WiFi 6 access point designed to deliver fast, reliable wireless connectivity across outdoor business and commercial environments. With dual-band WiFi 6 speeds of up to 3 Gbps, long-range coverage, professional antennas and an IP68 weatherproof enclosure, it is built for demanding outdoor deployments.
Key Features and Benefits
- AX3000 dual-band WiFi 6 speeds up to 3 Gbps
- 5 GHz speeds up to 2402 Mbps and 2.4 GHz speeds up to 574 Mbps
- OFDMA and MU-MIMO improve network efficiency for multiple devices
- 160 MHz channel bandwidth for high-speed 5 GHz connections
- Long-range outdoor coverage with high-power amplifiers and professional antennas
- IP68 weatherproof enclosure for demanding outdoor environments
- Omada Mesh enables flexible wireless network expansion
- Seamless Roaming supports smooth movement between access points
- 802.3at PoE+ and 48V Passive PoE support
- Centralized management through Omada SDN and Omada App
- Pole and wall mounting options with mounting kits included
- Supports 250+ concurrent clients
Fast and Reliable Outdoor WiFi 6
The EAP650-Outdoor combines WiFi 6 technologies including 1024-QAM, OFDMA and MU-MIMO to provide efficient wireless connectivity for multiple connected devices. Its dual-band design delivers up to 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz, for a combined AX3000-class wireless rate.
Designed for Long-Range Outdoor Coverage
Professional antennas and high-power amplifiers help provide strong wireless coverage across outdoor spaces. TP-Link specifies coverage distances of up to 200 m on 2.4 GHz and 300 m on 5 GHz under field-test conditions, with actual performance depending on the environment, client devices and network conditions.
Built for Outdoor Environments
The IP68 weatherproof enclosure provides protection for outdoor deployments. The EAP650-Outdoor is suitable for environments such as outdoor cafés, swimming pools, parks, gardens, yards, amphitheatres and other commercial outdoor areas.
Omada Mesh and Seamless Roaming
With Omada SDN, the EAP650-Outdoor supports Omada Mesh and Seamless Roaming for flexible deployments and smoother wireless connectivity across multiple access points. These functions require a compatible Omada SDN controller.
Flexible PoE Installation
The EAP650-Outdoor supports 802.3at PoE+ and 48V Passive PoE, allowing flexible installation without requiring a dedicated power connection at the access point. The included Passive PoE adapter is intended for dry indoor use only.
Additional Information:
Wireless Performance
WiFi Class: AX3000
5 GHz: Up to 2402 Mbps
2.4 GHz: Up to 574 Mbps
Frequency: 2.4 GHz and 5 GHz
Concurrent Clients: 250+
Channel Bandwidth: Up to 160 MHz on 5 GHz
Antennas: 2 × 4 dBi at 2.4 GHz and 2 × 5 dBi at 5 GHz
WiFi Features
OFDMA
MU-MIMO
Beamforming
Band Steering
Airtime Fairness
Load Balance
Rate Limit
Multiple SSIDs: Up to 16 total, 8 per band
Omada Mesh
Seamless Roaming with 802.11k/v/r
Automatic Channel Assignment
Transmit Power Control
Wireless Scheduling
Wireless Statistics
Outdoor Design & Coverage
2.4 GHz Coverage: Up to 200 m under field-test conditions
5 GHz Coverage: Up to 300 m under field-test conditions
Mounting: Pole and wall mounting
Operating Temperature: -30°C to 70°C (-22°F to 158°F)
Operating Humidity: 10%–90% RH, non-condensing
Network Interface & Power
PoE Input: 802.3at PoE+
Passive PoE: 48V
Maximum Power Consumption: 12.5W EU / 14.7W US
Reset Button: Yes
Passive PoE Adapter: Included
Wireless Security
Access Control
MAC Address Filtering
Wireless Client Isolation
SSID-to-VLAN Mapping
Rogue AP Detection
802.1X Support
WEP
WPA-Personal/Enterprise
WPA2-Personal/Enterprise
WPA3-Personal/Enterprise
Omada Management
Centralized Management: Omada Cloud-Based Controller, Hardware Controller and Software Controller
Cloud Access: Yes, requires an Omada controller
Zero-Touch Provisioning: Yes, requires Omada Cloud-Based Controller
Web-Based Management: Yes
SSH: Yes
SNMP: v1 and v2c
Syslog: Local and Remote
L3 Management: Yes
Multi-Site Management: Yes
Management VLAN: Yes
Email Alerts: Yes
Physical Specifications
Enclosure: IP68 weatherproof
Mounting: Pole/Wall Mounting
Installation: Outdoor wall or pole deployment
Package Contents
Passive PoE Adapter
Power Cord
Mounting Kits
Waterproof Kit
Installation Guide
Certifications & Requirements
Supported Systems: Windows XP, Vista, Windows 7, Windows 8, Windows 10, Windows 11 and Linux
***ONE YEAR LIMITED MANUFACTURER'S WARRANTY INCLUDED
Explore more TP-Link Omada networking products and wireless solutions here.
For more information regarding the TP-Link EAP650-Outdoor, visit the official TP-Link Omada website.
